Frame
OCLV Mountain Carbon main frame, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH Boost148, 12 mm thru axle, 160 mm travel
Fork
Fox Performance Elite Float 38, Float EVOL air spring, GRIP X damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt-X axle, 160 mm travel
Shock
Fox Performance Elite Float X, 2-position damper, 205mm x 65mm
Wheel front Size: S
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5"
Wheel front Size: M, L, XL
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Wheel rear
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 27.5''
Skewer rear
Bontrager Switch thru-axle, removable lever
Tyre Size: S, M, L, XL
Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5x2.50"
Tyre Size: M, L, XL
Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 29x2.50"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
Frame: 27.5x2.60", Fork: See manufacturer
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Controller
Bosch System Controller BRC3100, smart system
Motor
Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Rear derailleur
SRAM GX Eagle AXS, T-Type
Crank
SRAM GX, 160 mm length
Chainring
SRAM T-Type, 34T, steel
Cassette
SRAM Eagle XS-1275, T-Type,10-52, 12-speed
Chain
SRAM GX Eagle, T-Type, 12-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 36T
Saddle
Verse Short Comp, steel rails, 145 mm width
Seatpost Size: S
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length
Seatpost Size: M
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
Seatpost Size: L, XL
Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar
Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
Grips
Bontrager XR Trail Elite, nylon lock-on
Stem
Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 45 mm length
Brake
SRAM Maven Bronze 4-piston hydraulic disc
Brake rotor Size: S, M, L, XL
SRAM HS2, 6-bolt, 220mm
Brake rotor Size: S, M, L, XL
SRAM HS2, 6-bolt, 200mm
Rotor size
Max brake rotor sizes – Frame: 220 mm, Fork: see fork manufacturer
Mudguard
Trek 27.5" custom fender
Weight
M – 24.18 kg (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
