Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, rack and mudguard mounts, Boost 148, 120 mm travel
Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel
Shock
RockShox Deluxe Select R, 210x50 mm
Hub front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim Size
S , M , L , XL - Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
Rim Size
S , M , L , XL - Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
Spokes
14 g stainless steel, black
Tyre Size: S
Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40"
Tyre Size: M , L , XL
Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
Battery
Bosch PowerTube 600 Wh, smart system
Charger
Bosch standard 2A, 230V, smart system
Motor
Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Shifter
Shimano U6000, 10-speed
Rear derailleur
Shimano CUES U6000 GS
Crank
FSA Bosch CK-220, 36T ring, 165 mm length
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 38T
Saddle
Bontrager Verse P3, steel rails
Seatpost Size: S
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
Seatpost Size: M , L , XL
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Tektro Gemini SL 4 piston hydraulic brake
Brake rotor
Tektro, CentreLock, 203 mm
Rotor size
Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
Mudguard
Trek 27.5" custom fender
Weight
M – 24.58 kg (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
