Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, Boost148, 12 mm thru axle, 160 mm travel
Fork
RockShox Psylo Gold RC, DebonAir spring, Isolator RC damper, tapered steerer, 44 mm offset, Boost 110, 15 mm Maxle Stealth, 160 mm travel
Shock
RockShox Deluxe Select+ RT, 205 mm x 65mm
Hub front
Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, Shimano Micro Spline freehub, Boost148, 12 mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Tyre Size: S, M, L, XL
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40"
Tyre Size: M, L, XL
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
Frame: 27.5x2.60", Fork: See manufacturer
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 2A, 230V, smart system
Controller
Bosch System Controller BRC3100, smart system
Motor
Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore M6100, long cage
Crank arm
E*thirteen E*spec Plus, 160 mm length
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 36T
Saddle
Bontrager Verse P3, steel rails
Seatpost Size: S
TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm
Seatpost Size: M, L, XL
TranzX JD-YSI34, 170mm travel, internal routing, 34.9 mm
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Brake
Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
Brake rotor
Shimano RT66, 6-bolt, 203 mm
Rotor size
Max brake rotor sizes – Frame: 220 mm, Fork: see fork manufacturer
Mudguard
Trek custom mudguard
Weight
M - 25.28 kg (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
