It's right for you if... You don't ever want to miss a shift again, and you value the predictability, smoothness and lightning-fast shifting of a new wireless Di2 electronic drivetrain. You want an ultra-light, ultra-fast carbon frame and carbon wheels, plus the power and confidence of hydraulic disc brakes.
Atriði 2
The tech you get A lightweight and aerodynamic 500 Series OCLV Carbon frame and fork, an all-new wireless Shimano Ultegra Di2 2x12 electronic drivetrain, Bontrager Aeolus Pro 37 carbon wheels and Shimano Ultegra hydraulic flat-mount disc brakes.
Atriði 3
The final word Our ultra-light aero carbon frame, electronic shifting, carbon wheels and hydraulic disc brakes make this bike an outstanding choice for the rider who wants a speedy, lightweight racing bike that beats everyone up massive climbs and down epic descents.
Atriði 4
Why you'll love it
Atriði 5
All-new wireless Ultegra Di2 delivers ever faster, smoother and more responsive shifts than ever
Atriði 6
Aerodynamic tube shaping makes this our fastest Émonda SL platform ever – on flats and climbs alike
Atriði 7
This bike is fully capable of taking on the biggest climbs, steepest descents and fastest sprints
Atriði 8
Like every Émonda, it's light and fast – and it's backed by our lifetime warranty
Atriði 9
Hydraulic disc brakes give you stopping power and control in any weather, on any road
Frame
Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle
Shifter
Shimano Ultegra R8170 Di2, 12-speed
Front derailleur
Shimano Ultegra R8150 Di2, braze-on, down swing
Rear derailleur
Shimano Ultegra R8150 Di2, 34T max cog
Crank Size: 50, 52
Shimano Ultegra R8100, 52/36, 170 mm length
Crank Size: 54, 56, 58
Shimano Ultegra R8100, 52/36, 172.5 mm length
Crank Size: 60, 62
Shimano Ultegra R8100, 52/36, 175 mm length
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano Ultegra R8100, 11-30, 12 speed
Chain
Shimano Ultegra/XT M8100, 12-speed
Max. chainring size
1x: 50T, 2x: 53/39
Saddle
Bontrager Aeolus Comp, steel rails, 145 mm width
Seatpost Size: 50, 52, 54
Bontrager carbon seat mast cap, 20 mm offset, short length
Seatpost Size: 56, 58, 60, 62
Bontrager carbon seat mast cap, 20 mm offset, tall length
Handlebar Size: 50
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 38 cm width
Handlebar Size: 52
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 40 cm width
Handlebar Size: 54, 56, 58
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 42 cm width
Handlebar Size: 54, 56, 58
Bontrager Pro IsoCore VR-SF, 42cm
Handlebar Size: 60, 62
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 44 cm width
Handlebar Size: 60, 62
Bontrager Pro IsoCore VR-SF, 44cm
Handlebar tape
Bontrager Supertack Perf tape
Stem Size: 50
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Stem Size: 52, 54
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Stem Size: 56
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Stem Size: 58, 60, 62
Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Brake
Shimano Ultegra hydraulic disc, BR-R8170 flat mount caliper, resin pad w/fin
Brake rotor
Shimano MT800, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 160mm front & rear
Charger
Charging cable included
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg.
