Frameset Frame
Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle Fork - Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm thru axle Frame fit - H1.5 Race
Wheels Hub front
Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle Skewer front - Bontrager Switch thru axle, removable lever Hub rear - Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle Skewer rear - Bontrager Switch thru-axle, removable lever Rim - Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve Max tyre size - 30c
Drivetrain Shifter Size: 47, 50, 52
Shimano 105 R7025, short-reach lever, 11-speed Shifter Size: 54, 56, 58, 60, 62 - Shimano 105 R7020, 11-speed Front derailleur - Shimano 105 R7000, braze-on Rear derailleur - Shimano 105 R7000, short cage, 30T max cog Crank Size: 47 - Shimano 105 R7000, 50/34 (compact), 165 mm length Crank Size: 50, 52 - Shimano 105 R7000, 50/34 (compact), 170 mm length Crank Size: 54, 56, 58 - Shimano 105 R7000, 50/34 (compact), 172.5 mm length Crank Size: 60, 62 - Shimano 105 R7000, 50/34 (compact), 175 mm length Bottom bracket - Praxis, T47 threaded, internal bearing Cassette - Shimano 105 R7000, 11-30, 11-speed Chain - Shimano 105 HG601, 11-speed Max. chainring size - 1x: 50T, 2x: 53/39T
Components Saddle Size: 47, 50, 52
Bontrager P3 Verse Comp, steel rails, 155 mm width Saddle Size: 54, 56, 58, 60, 62 - Bontrager P3 Verse Comp, steel rails, 145 mm width Seatpost Size: 47, 50, 52, 54 - Bontrager alloy seat mast cap, 10 mm offset, short length Seatpost Size: 56, 58, 60, 62 - Bontrager alloy seat mast cap, 10 mm offset, tall length Handlebar Size: 47, 50 - Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width Handlebar Size: 52 - Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width Handlebar Size: 54, 56, 58 - Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width Handlebar Size: 60, 62 - Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width Handlebar tape - Bontrager Supertack Perf tape Stem Size: 50 - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length Stem Size: 52, 54 - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length Stem Size: 56 - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length Stem Size: 58, 60, 62 - Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length Brake - Shimano 105 hydraulic disc Brake rotor - Shimano SM-RT70, CenterLock, 160 mm
Weight Weight 56
9.15 kg Weight limit - This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg.
