Atriði 1
It's right for you if... You want all the advantages of a bike built to be the lightest in its class, with a wallet-friendly alloy frame that has the sleek looks and handling you'd expect only from a carbon frame. You also want the confident stopping power that disc brakes provide.
Atriði 2
The tech you get An ultralight 300 Series Alpha Aluminium frame with aerodynamic Kammtail shaped tubes and Invisible Weld Technology, an Émonda SL carbon fork that absorbs vibration from the road, internal cable routing in both the frame and fork, a full 2x11 Shimano 105 drivetrain for dependable shifting, powerful flat-mount hydraulic disc brakes and tubeless-ready wheels.
Atriði 3
The final word The Émonda ALR 5 gives you the sleek looks of carbon without the sticker shock. Its advanced alloy frame is built to perform, and pairs with disc brakes and a reliable Shimano 105 drivetrain to give it the race-ready edge.
Atriði 4
Why you'll love it
Atriði 5
The all-new frame is lighter and sleeker than previous ALR models and features aerodynamic Kammtail tubes with even cleaner cable routing
Atriði 6
It climbs fast, corners on rails, and descends with confidence
Atriði 7
Disc brakes offer better braking performance and extra clearance for wider, more comfortable tyres
Atriði 8
It shares the race geometry of our highest-end carbon Émonda race bikes, and it gives you a ride quality that stands up in every way to far more expensive carbon bikes
Atriði 9
Internal cable routing extends the life of your cables and adds to the bike's sleek look
Frame
Ultralight 300 Series Alpha Aluminium, Invisible Weld technology, tapered head tube, internal cable routing, flat mount disc, 142x12 mm thru axle
Fork
Émonda ALR full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm thru axle
Shifter
Shimano 105 R7020, 11-speed
Front derailleur
Shimano 105 R7000, braze-on
Rear derailleur
Shimano 105 R7000, short cage, 30T max cog
Crank Size: 47
Shimano 105 R7000, 50/34 (compact), 165 mm length
Crank Size: 50, 52
Shimano 105 R7000, 50/34 (compact), 170 mm length
Crank Size: 54, 56, 58
Shimano 105 R7000, 50/34 (compact), 172.5 mm length
Crank Size: 60, 62
Shimano 105 R7000, 50/34 (compact), 175 mm length
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano 105 R7000, 11-30, 11 speed
Chain
Shimano 105 HG601, 11-speed
Max. chainring size
1x: 48T, 2x: 53/39 (Shimano), 48/35 (SRAM)
Saddle Size: 47, 50, 52
Bontrager Verse Short Comp, steel rails, 155 mm width
Saddle Size: 54, 56, 58, 60, 62
Bontrager Verse Short Comp, steel rails, 145 mm width
Seatpost Size: 47
Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length
Seatpost Size: 50, 52, 54, 56, 58, 60, 62
Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
Handlebar Size: 47, 50
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width
Handlebar Size: 52
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width
Handlebar Size: 54, 56, 58
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width
Handlebar Size: 60, 62
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width
Handlebar tape
Bontrager Supertack Perf tape
Stem Size: 47
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Stem Size: 50
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Stem Size: 52, 54
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Stem Size: 56, 58
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Stem Size: 60, 62
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Brake
Shimano 105 hydraulic disc
Brake rotor
Shimano RT70, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 160mm front & rear
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg.
