Why you'll love it
Atriði 2
This versatile bike is fully capable of taking on rough roads, challenging rides, races and even light gravel riding
Atriði 3
The unique IsoSpeed Carbon fork, which swoops forward toward the dropouts, absorbs vibrations from the road so your arms won't fatigue as quickly
Atriði 4
Setting your wheels up as tubeless reduces the overall weight of your bike and the chance you’ll get a flat
Atriði 5
Bigger tyre clearance lets you run wider tyres for more traction and stability on rail trails and other light gravel roads
Atriði 6
DuoTrap S compatibility makes it easy to wirelessly track your rides, so you can set goals and watch yourself reach them
Frame
100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle
Fork
Domane AL carbon, tapered alloy steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Hub front
Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Skewer front
Bontrager Switch thru axle, removable lever
Hub rear
Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Affinity Disc, Tubeless Ready, 28-hole, 21 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32 c
Max tyre size
35c without mudguards, 32c with mudguards
Shifter
Shimano 105 R7020, 11-speed
Front derailleur
Shimano 105 R7000, 31 mm clamp
Rear derailleur
Shimano 105 R7000, long cage, 34T max cog
Crank Size: 44
Shimano 105 R7000, 50/34 (compact), 165 mm length
Crank Size: 49, 52
Shimano 105 R7000, 50/34 (compact), 170 mm length
Crank Size: 54, 56
Shimano 105 R7000, 50/34 (compact), 172.5 mm length
Crank Size: 58, 61
Shimano 105 R7000, 50/34 (compact), 175 mm length
Bottom bracket
Prowheel PW-BB73+, 68/73 mm, threaded external
Cassette
Shimano 105 HG700-11, 11-34, 11 speed
Atriði 10
Max. chainring size 1x: 42t, 2x: 50/34
Saddle Size: 44, 49, 52
Bontrager Verse Comp, steel rails, 155 mm width
Saddle Size: 54, 56, 58, 61
Bontrager Verse Comp, steel rails, 145 mm width
Seatpost Size: 44, 49
Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length
Seatpost Size: 52, 54, 56, 58, 61
Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
Handlebar Size: 44, 49
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 38 cm width
Handlebar Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 40 cm width
Handlebar Size: 54, 56
Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, internal Di2 routing, 93 mm reach, 123 mm drop, 42 cm width
Handlebar Size: 58, 61
Bontrager Elite IsoZone VR-CF, alloy, 31.8 mm, internal Di2 routing, 93 mm reach, 123 mm drop, 44 cm width
Handlebar tape
Bontrager Supertack Perf tape
Stem Size: 44
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Stem Size: 49
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Stem Size: 52, 54
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Stem Size: 56, 58
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Stem Size: 61
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Head set
FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake
Shimano 105 hydraulic disc
Brake rotor
Shimano RT70, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 160 mm front and rear
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg.
