Frame
Alpha Platinum Aluminum, internal cable routing, dealer removable battery, rack and mudguard mounts, post mount disc, kickstand mount
Fork
FX Carbon, hidden fender mounts, flat mount disc, internal routing, 100x12 thru axle
Hub front
Formula alloy, CenterLock disc, 100x12 mm thru-axle
Skewer front
Bontrager Switch thru axle
Hub rear
Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear
Bontrager Switch thru axle
Rim
Bontrager Paradigm, Tubeless Ready, 32-hole, 21 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager H2 Hard Case Lite, wire bead, 30 tpi, 700x40 mm
Computer
TQ LED display with Bluetooth & ANT+ connectivity
Motor
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
Shifter
Shimano U6000, 10-speed
Rear derailleur
Shimano CUES U6000 GS
Crank
ProWheel Alloy, 46T narrow-wide chain ring, 170 mm arm length ISIS spline
Cassette
Shimano CUES LG400, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
Bontrager City pedals
Max. chainring size
1x: 46T
Saddle
Bontrager Verse Comp, steel rails, 165 mm width
Seatpost
Bontrager Comp, 6061 alloy, 31.6 mm, 8 mm offset, 400 mm length
Handlebar/stem (integrated) Size: XS, S, M
Bontrager Integrated handlebar/stem, 15 mm virtual handlebar rise, 640 mm width, 0-degree stem rise, 90 mm stem (virtual) length
Handlebar/stem (integrated) Size: L
Bontrager Integrated handlebar/stem, 15 mm virtual handlebar rise, 680 width, 0 degree stem rise, 90 mm stem (virtual) length
Grips
Bontrager Satellite Elite, alloy lock-on
Brake
Shimano hydraulic disc, RS600 lever, RS405 calliper
Brake rotor Size: XS, S, M, L
Shimano RT-MT800, CentreLock, 180 mm
Brake rotor Size: XS, S, M, L
Shimano EM810, CenterLock 160 mm
Rotor size
Max brake rotor sizes: 180 mm front and rear
Light Size: XS, S, M, L
Herrmans H-Black MR9-E
Light Size: XS, S, M, L
Spanninga GLOW XE for e-bike
Kickstand
Pletscher Comp 18
Cargo rack
MIK-compatible alloy rear rack
Mudguard
Trek FX+ 7 Rear Mudguard
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
